UNI T UTD2072CEX II Digital Storage Oscilloscope 2 Channel DSO

UNI T UTD2072CEX II Digital Storage Oscilloscope 2 Channel DSO

Condition: New
Brand: UNI-T
Availability: In Stock
Advance Payment Only


Ask Price

An oscilloscope is a laboratory instrument commonly used to display and analyze the waveform of electronic signals. In effect, the device draws a graph of the instantaneous signal voltage as a function of time. UNI-T UTD2072CEX-II digital oscilloscope is a 2 channel 70MHz bandwidth high-performance device. It has a sampling rate of 1GS/s. Digital Storage CRO is ergonomic, lightweight, universal instruments designed for engineers. Sampling Oscilloscope is suitable for field testing and analyzing time-based voltage signals in a mobile environment

Features Of UNI-T UTD 2072CEX-II Oscilloscope DSO Scopemeter:

  • 70MHz bandwidth, 1GSa/s real-time sampling rate
  • 2 channels
  • 25kpts memory depth
  • 20,000wfms/s waveform acquisition rate
  • 2ns/div~50s/div time-base
  • Trigger modes: Edge, Pulse Width, Runt, Over-amplitude, Slope and Video
  • Calibration Signal Output: 10Hz, 100Hz, 1kHz (default), 10kHz and 100kHz
  • Input calibration signal only by pressing a button
  • 10Mpts waveform recording
  • 8-inch TFT LCD, WVGA (800×480)
  • USB OTG and Pass/Fail interfaces

Specifications Of 2 Channel Digital Storage Oscilloscope:

  1. Channels: 2
  2. Bandwidth: 70MHZ
  3. Sample Rate: 1GS/s
  4. Rise Time: ≤5ns
  5. Memory Depth: 25 kpts
  6. Waveform Acquisition Rate: ≥2000wfms/s
  7. Vertical Sensitivity: 1mV/div-20V/div (1MΩ)
  8. Time-base Range: 2ns/div~50s/div
  9. Storage: Setup, Wave, Bitmap
  10. Trigger Modes: Edge, Pulse, Video, Slope, Alternate
  11. Interface: USB OTG,Pass/Fail
  12. Power: 100-240VAC, 40-440Hz
  13. LCD Size: 7 Inches 64K Color TFT LCD, 800×480
  14. Color: White and Grey
  15. Dimension: 306mm ×147mm × 122mm

Package Include:

  • 1x Oscilloscope
  • 2x Probe (1×,10× switchable)
  • 1x power cord
  • 1x USB cable
