Sonel CMP-401 Digital Clamp-on multimeter in Pakistan

Description

DC current measurement

DC voltage measurement

Resistance measurement

• continuity test with acoustic signalling (beeper) for resistance below 50.

Temperature measurement

Frequency measurement

Capacitance measurement

• • safe, insulated measuring clamps,
  • double molded housing,
  • autoranging/manual range selection,
  • DATA HOLD function, for holding measured values,
  • backlit LCD,
  • REL function,
  • over range indication,

  AUTO-OFF function.

  DC current measurement

  and AC current. . AC/

  DC voltage measurement

  up to 600 V.

  Resistance measurement

  and continuity test:

• • continuity test with acoustic signalling (beeper) for resistance below 50 Ω.

Temperature measurement

(Fahrenheit and Celsius units).

Frequency measurement

.

Capacitance measurement

• Diode test.
• Additionally:
• • safe, insulated measuring clamps,
  • double molded housing,
  • autoranging/manual range selection,
  • „DATA HOLD” function, for holding measured values,
  • backlit LCD,
  • „REL” function,
  • over range indication,
• „AUTO-OFF” function.
• Electric security:
• • measurement category: CAT III 600 V acc. to EN 61010 - 1:2004
  • protection class acc. to EN 60529: IP40
• Other technical data:
• • power supply: 9 V battery type 6LR61
  • display: 4000 counts, backlit LCD
  • continuity test: I<0,5 mA, sound signal for R<50 Ω
  • diode test: I = 0,3 mA, U0 = 1,5 V DC
  • over range indication: 0L displayed
  • sampling rate: 2 times per second
  • input impedance: 10 MΩ (V DC and V AC)
  • clamp size: opening 30 mm (1,2”)
  • auto power OFF: approx. 30 min.
  • dimensions: 197 x 70 x 40 mm
  • weight: 183 g
  • accordance with following standards: EN 61010 - 1:2004, EN 61010 - 2 - 032
  • quality standard: ISO 9001
• Rated operational conditions:
• • operating temperature: 0...+40°C
  • storage temperature: -20...+60°C
  • operating humidity: max 80% up to 31°C; decreasing linearly to 50% at 40°C
  • operating altitude: max 2000 m

Temperature measurement

• Range Accuracy
*
• -20,0...760°C ±(3% m.v. + 5°C)
• -4,0...1400°F ±(3% m.v. + 9°F)
• *probe (K type) accuracy not included

Frequency measurement

• Range Accuracy
• 10 Hz ... 10 kHz ±(1,5% m.v. + 2 digits)
• • csensitivity: 100 V (<50 Hz), 50 V (50…400 Hz); 15 V (401 Hz…10 kHz)

AC current measurement

• Range Resolution Accuracy
• 40,00 A 0,01 A ±(2,5% m.v. + 8 digits)
• 400,0 A 0,1 A ±(2,8% m.v. + 5 digits)
• • frequency range: 50...60 Hz.

DC current measurement

• Range Resolution Accuracy
• 40,00 A 0,01 A ±(2,5% m.v. + 5 digits)
• 400,0 A 0,1 A ±(2,8% m.v. + 5 digits)

AC voltage measurement

• Range Resolution Accuracy
• 400,0 mV 0,1 mV ±(1,5% m.v. + 30 digits)
• 4,000 V 0,001 V ±(1,5% m.v. + 5 digits)
• 40,00 V 0,01 V ±(1,5% m.v. + 5 digits)
• 400,0 V 0,1 V ±(1,5% m.v. + 5 digits)
• 600,0 V 1 V ±(2% m.v. + 5 digits)
• • frequency range: 50...400 Hz.

DC voltage measurement

• Range Resolution Accuracy
• 400,0 mV 0,1 mV ±(0,8% m.v. + 2 digits)
• 4,000 V 0,001 V ±(1,5% m.v. + 2 digits)
• 40,00 V 0,01 V ±(1,5% m.v. + 2 digits)
• 400,0 V 0,1 V ±(1,5% m.v. + 2 digits)
• 600,0 V 1 V ±(2% m.v. + 2 digits)

Resistance measurement

• Range Resolution Accuracy
• 400,0 Ω 0,1 Ω ±(1,0% m.v. + 4 digits)
• 4,000 kΩ 0,001 kΩ ±(1,5% m.v. + 2 digits)
• 40,00 kΩ 0,01 kΩ ±(1,5% m.v. + 2 digits)
• 400,0 kΩ 0,1 kΩ ±(1,5% m.v. + 2 digits)
• 4,000 MΩ 0,001 MΩ ±(2,5% m.v. + 3 digits)
• 40,00 MΩ 0,01 MΩ ±(3,5% m.v. + 5 digits)

Capacitance measurement

• Range Resolution Accuracy
• 40,00 nF 0,01 nF ±(4% m.v. + 20 digits)
• 400,0 nF 0,1 nF ±(3% m.v. + 5 digits)
• 4,000 nF 0,001 μF ±(3% m.v. + 5 digits)
• 40,00 nF 0,01 μF ±(3% m.v. + 5 digits)
• 100,0 nF 0,1 μF ±(4% m.v. + 10 digits)
• m.v.”- measured value

Package includes:

1xSonel CMP-401 Digital Clamp-on multimeter
