Unassembled Arduino P10 LED Dot Matrix Display Driver Shield
Other Modules

Unassembled Arduino P10 LED Dot Matrix Display Driver Shield

Condition: New
Availability: In Stock
Advance Payment Only
Share:

SKU: ,D13,TMD,Th5,KRT

Rs.400 Rs. 500

Arduino P10 LED Dot Matrix Display Driver Shield ,This is plug and play type Arduino Shield which enables you to add Scrolling Led Display to your project. Arduino P10 LED Dot Matrix Display Driver Shield is very simple to use this shield with your arduino uno r3. Just plug it with arduino uno and Panel Data wire to Shield and its ready to program. 512 LED matrix panel has on-board controller circuitry designed to make it easy to use straight from your board. Clocks, status displays, graphics readouts and all kinds of impressive display projects are easy to create using this display. The photos don’t do this display justice: it’s stunningly bright, so put on your sunglasses before you fire it up! This handy Dot Matrix Display Connector allows you to plug an LED panel with a HUB12 interface straight in to an Arduino-compatible board.

Features:

  1. Suits displays with a HUB12 interface
  2. Pin spacing to suit Arduino compatible headers
  3. Connector for 10-way ribbon cable for DMD (not included)
  4. Arduino compatible library, graphics functions and example support

Compatibility

Compatible with the following LED panels:

  1. Red DMD
  2. Blue DMD
  • Green DMD
  • White DMD
  • Yellow DMD
    1. Red DMD
    2. White DMD
    3. Blue DMD

    Resources

    1. Dot Matrix Display Quickstart Guide (1MB PDF)
    2. Using your Dot Matrix Display
    3. Dot Matrix Display Driver library (software, example and demo program, install notes) on github
    4. Note the [ZIP] button on github allows you to download the whole library package as a zip file
    5. Daisy-chaining multiple displays
    6. Discuss in the forum
    7. DMDCON DMD Connector board Schematic (PDF)
    8. Making a laser-cut desk stand for the DMD

    Package Includes:

    1x Arduino P10 LED Dot Matrix pcb

    1x Male Haeder

    1x Female Header

    1x Green Connector
