CMP-1006 Digital Clamp-on multimeter in Pakistan

Description

(TRUE RMS) up to 1000 A. Measurement of INRUSH current in start-up phase of electrical device (high frequency of sampling) AC/DC voltage measurement(TRUE RMS) up to 600 V.

Resistance measurement and continuity test:

• continuity test with acoustic signalling (beeper) for resistance below 40.
• Temperature measurement(Fahrenheit and Celsius units).
• Frequency measurement
• Duty cycle measurement
• Diode test.

Additionally:

• safe, insulated measuring clamps,
• autoranging/manual range selection,
• DATA HOLD function, for holding measured values,
• backlit LCD,
• DC ZERO mode of measurement for DC current, possibility to zero the display and reading relative actual value less stored zero value,
• MAX/MIN function,
• over range indication,
• AUTO-OFF function.

Electric security:

• measurement category: CAT III 600 V acc. to EN 61010 - 1:2004
• protection class acc. to EN 60529: IP40

Other technical data:

• power supply: 9 V battery type 6LR61
• display: 6600 counts, backlit LCD
• continuity test: threshold 40 Ω; test current < 0,5 mA
• diode test: test current of 0,3 mA, typical open circuit voltage < 3 V DC, typical
• low battery indication: BAT displayed
• over range indication: 0L displayed
• sampling rate: 2 times per second
• INRUSH: integration time 100 ms
• temperature sensor: type K thermocouple
• input impedance: 10 MΩ (V DC and V AC)
• AC bandwidth: 50...400 Hz (A AC and V AC)
• auto power OFF: approx. 25 min.
• dimensions: 229 x 80 x 49 mm
• weight: 303 g
• accordance with following standards: EN 61010 - 1:2004, EN 61010 - 2 - 032
• quality standard: ISO 9001

Rated operational conditions:

• internal clamp diameters: d1 = 36 mm/d2 = 52 mm
• operating temperature: +5...+40°C
• storage temperature: -20...+60°C
• operating humidity: max 80% up to 31°C decreasing linearly to 50% at 40°C
• storage humidity: <80%
• operating altitude: max 2000 m

AC/DC current measurement (TRUE RMS)

Range Resolution Accuracy (DC) Accuracy (AC) 0...659,9 A 0,1 A ±(2,5% m.v. +5 dgt) ±(2,5% m.v + 8 dgt) for f = 50...60 Hz 660...1000 A 1 A ±(2,8% m.v. +8 dgt) ±(2,8% m.v. + 8 dgt) for f = 50...60 Hz

DC voltage measurement

Range Resolution Accuracy 0...6,599 V 0,001 V ±(1,5% m.v. + 3 dgt) 6,60...65,99 V 0,01 V ±(1,5% m.v. + 3 dgt) 66,0...600,0 V 0,1 V ±(1,5% m.v. + 3 dgt)

AC voltage measurement (TRUE RMS)

Range Resolution Accuracy 0...6,599 V 0,001 V ±(1,8% m.v. + 5 dgt) for f = 50...60 Hz 6,60...65,99 V 0,01 V ±(1,8% m.v. + 5 dgt) for f = 50...60 Hz 66,0...600,0 V 0,1 V ±(1,8% m.v. + 5 dgt) for f = 50...60 Hz

Resistance measurement

Range Resolution Accuracy 0,0...659,9 Ω 0,1 Ω ±(1,0% m.v. + 4 dgt) 0,660...6,599 kΩ 0,001 kΩ ±(1,5% m.v. + 2 dgt) 6,60...65,99 kΩ 0,01 kΩ ±(1,5% m.v. + 2 dgt) 66,0...659,9 kΩ 0,1 kΩ ±(1,5% m.v. + 2 dgt) 0,660...6,599 MΩ 0,001 MΩ ±(2,5% m.v. + 3 dgt) 6,60...66,00 MΩ 0,01 MΩ ±(3,5% m.v. + 5 dgt)

Frequency measurement

Range Resolution Accuracy 30,0...999,9 Hz 0,1 Hz ±(1.2% m.v. + 2 dgt) sensitivity:30...5 kHz:10 Vrms min. 5 kHz...15 kHz:40 Vrms min. for 20%...80% duty cycle 1,000...9,999 kHz 0,001 kHz ±(1.2% m.v. + 2 dgt) sensitivity:30...5 kHz:10 Vrms min. 5 kHz...15 kHz:40 Vrms min. for 20%...80% duty cycle 10,00...15,00 kHz 0,01 kHz ±(1.2% m.v. + 2 dgt) sensitivity:30...5 kHz:10 Vrms min. 5 kHz...15 kHz:40 Vrms min. for 20%...80% duty cycle

Temperature measurement

Range Resolution Accuracy -20...760°C 0,1°C ±(3,0% m.v. + 5°C) -4...1400°F 0,1°F ±(3,0% m.v. + 9°F)

Duty cycle measurement

Range Resolution Accuracy 10,0...94,9% 0,1% ±(1,2% m.v. + 2 dgt)

• pulse width: 100μs...100 ms,
• frequency range: 30 Hz...5 kHz,
• sensitivity: 30 Hz...5 kHz: 10 Vrms, 5 kHz...15 kHz: 40 Vrms.

„m.v.”- measured value

Package includes:

1x
