24VDC 6 pin JQX 15F T90 Electromagnetic Induction Power Relay
Relays & Connector

24VDC 6 pin JQX 15F T90 Electromagnetic Induction Power Relay

Condition: New
Availability: In Stock
Advance Payment Only
Share:

SKU: B419,TMD,Th,KRT

Rs.150 Rs. 188

24VDC 6 pin JQX-15F(T90) Electromagnetic Induction Power Relay is an electrically operated switch. Electromagnetic Induction Power Relays used an electromagnet to mechanically operate a switch, but other operating principles are also used, such as solid-state relays. Relays are used where it is necessary to control a circuit by a separate low-power signal, or where several circuits must be controlled by one signal. The first relays were used in long-distance telegraph circuits as amplifiers: they repeated the signal coming in from one circuit and re-transmitted it on another circuit. Relays were used extensively in telephone exchanges and early computers to perform logical operations.

Features of 24VDC 6 pin JQX-15F(T90) Electromagnetic Induction Power Relay:

  • 100% Brand new and High quality.
  • Electronic components, Industrial supplies, Synthetic accessories include Copper Post, Sensitive Resistor Photoresistor, Potentiometers, Rocker Switch, Module board, Temperature Controller, Proximity Switch, Rectifier, Nuts Bolt Screw, Toggle Clamp, Fasteners & Hardware, Home & Garden.
  • Ultra-small volume
  • Low Power Consumption
  • Large Load contact
  • High sensitivity

Specifications of 24VDC 6 pin JQX-15F(T90) Electromagnetic Induction Power Relay:

Classification PCB Relay Product Model JQX-15F(T90) Contact Form 1Z Coil Voltage 5/6/9/12//24/48VDC Operate Voltage ≤ 3.8/4.5/6.8/9.0/13.5/18.0/27.0/36.0VDC Release Voltage ≥ 0.5/0.6/0.9/1.2/1.8/2.4/3.6/4.8VDC Coil Power(W) 0.93W Contact Rating 1H: 30A; 1Z: 20A (250VAC / 28VDC) Contact Resistance 100mohm Insulation Resistance 100mohm (500VDC) Between Open Contact 1500VAC 1min Between Coil and Contact 2000VAC 1min Electrical Life 1*105 Mechanical Life 1*107 Ambient Temperature -25 ~ +60°C Outline Dimension(L*W*H) 32.5*27.5*20.5 (mm) Mounting Form PCB Terminal

Package Includes:

  • 1 x 24VDC 6 pin JQX-15F(T90) Electromagnetic Induction Power Relay
