True RMS Digital AC/DC Clamp Meter 2500A UNI T UT222
Clamp Meters

True RMS Digital AC/DC Clamp Meter 2500A UNI T UT222

Condition: New
Brand: UNI-T
Availability: In Stock
Advance Payment Only


Ask Price

UNI-T UT222 is 2500A AC/DC digital clamp meter. ut222 ensures stable performance, safety, and reliability for measuring up to 2500A AC current. Handheld Digital AC/DC Clamp Multimeter is designed with overload protection for all ranges, perfect for all professionals measuring currents up to 2500A.UT222 Tong tester is used to measure AC/DC Current, Voltage, Resistance, Capacitance, Temperature, and Frequency

Features Of Portable Handheld Auto-range Digital Clamp Ampere Meter UT222:

  • 1000 measurement memory
  • auto and manual ranging
  • automatic power-off
  • current monitor output for waveform viewing (1A/1mV)
  • HOLD function
  • low battery indicator
  • low-pass filter
  • measures starting currents
  • MIN/MAX function
  • overload indicator
  • polarization indicator
  • REL function

Specifications Of UNI-T UT222 DCA ACA Digital True RMS Tong Multitester:

  1. Power: 9V Batteries (6LF22)
  2. LCD Display: 43mm x 30mm
  3. Dimension: 298mm x 100mm x 48mm
  4. Color: Red and Grey
  5. Jaw Capacity: 63mm
  6. Duty cycle: 0.1%~99.9%
  7. DC voltage:
    • Range:6V/60V/600V/1000V
    • Accuracy: ±(0.5%+2)
  8. DC current:
      • Range: 600A/2500A
      • Accuracy: ±(1.5%+5)
  9. AC voltage:
    • Range: 6V/60V/600V/1000V
    • Accuracy: ±(1.2%+5)
  10. AC current:
      • Range: 600A/2500A
      • Accuracy: ±(1.5%+5)
  11. Resistance:
    • Range: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ
    • Accuracy: ±(1%+2)
  12. Capacitance:
    • Range: 60nF/600nF/6uF/60uF/600uF/6000uF/60mF
    • Accuracy: ±(3.0%+5)
  13. Frequency:
    • Range: 60Hz/600Hz/6kHz/60kHz/600kHz/6MHz/60MHz
    • Accuracy: ±(0.1%+3)
  14. Temperature(°C):
    • Range: -40°C ~ 1000°C
    • Accuracy: ±(1.0%+8)
  15. Temperature(°F):
    • Range: -40°F ~ 1832°F
    • Accuracy: ±(1.0%+12)

Package Include:

  • 1x clamp meter 2500A UNI-T UT222

Best Online Shopping website for Modern Digital portable True RMS DCA ACA Clamp meter 2500A UT222 AC Voltmeter Ammeter and Resistance MultiTester in cheap price in Karachi Lahore Islamabad Rawalpindi Sukkur Peshawar Multan Quetta Faisalabad and all over Pakistan
