80W High Quality iMAX B6-AC B6AC Lipo NiMH 3S RC Battery Balance Charger Adapter

IMAX B6AC Charger/Discharger 1-6 Cells (Copy) charger to Charge at home on 110/240v or in the field on 12v with this great dual power charger. The B6AC handles both! The iMAX B6-AC is a rock-solid charger that is able to charge, balance and discharge Li-ion, LiPo, LiFe (A123), NiCd, NiMH, and PB batteries. New updated features also include internal resistance and capacity checker, along with brushed motor driver, hot wire foam cutter output, and brushless motor RPM checker. Manual

Note: This charger has a JST-XH charge plug, which makes it compatible with Zippy, HXT, TURNIGY and any pack with a JST adapter. This package does not include JST-XH connector

Features:

1. AC 100~240v or 12V DC input
2. The cables come with a fitted fuse.
3. Microprocessor controlled
4. Li-ion, LiPo, and LiFe capable
5. Input voltage monitoring. (Protects car batteries at the field)
6. Battery break-in and cycling feature
7. Data storage (Store up to 5 packs in memory)
8. Internal resistance checker to see pack health
9. Delta-peak sensitivity
10. Individual cell balancing
11. EU Plug to IEC C13 which is used in devices such as ac adapters, digital cameras, camcorders, monitors, printers, Direct TV and more!

Package Includes :

1 x Imax B6 AC Dual Power Battery Charger. 1 x 100 – 250V Power Supply Cord. 1 x T plug with banana connector charging cable. 1 x DC cable with Alligator Clip charging connector. 1 x T plug with Alligator Clip connector charging cable. 1 x T plug with Futaba connector charging cable. 1 x T plug with JST connector charging cable. 1 x English manual.

Power Supply Cord Details:

1. Total length: 1 meter.
2. Voltage : 100 – 250 VAC
3. Current : 2.5A Max.
4. Plug Type: 1. Female End Type: IEC(To Charger)
5. 2. Male End Type: EU plug (To Power Distribution Board).

AC Input Voltage

100 ~ 240v or 12V DC input.

DC Input Voltage

11~18 V DC

Output Power(Watt)

50 W Max.

Charge Current Range

0.1A ~5.0A

Maximum Discharge Power

5 W

Dischage Current Range

0.1 A ~ 1.0 A

Drain Current for Balancing Li-Po's

300 mA / Cell

Li-ion/Po cell count

1 ~ 6 Cells

NiCd/NiMH cell count

1 ~ 15 Cells

Pb battery voltage

2V ~ 20V

Dimensions (mm) LxWxH

133 x 87 x 33

Weight (gm)

580

Shipment Weight

0.07 kg

Shipment Dimensions

15 x 10 x 7 cm
