Texas Instruments

TM4C123GXL TM4C123G LaunchPad Evaluation Kit in Pakistan

Condition: New
Availability: In Stock
Share:     Faceook Twitter

SKU: 2405,D90,IMP,Th2,KRT137

Rs.4600 Rs. 5750

This TM4C123GXL TM4C123G LaunchPad Evaluation board in Pakistan is a low-cost evaluation board from Texas Instruments.TM4C123G Tiva C Series LaunchPad highlights the TM4C123GH6PM microcontroller with a USB 2.0 device interface and hibernation module. This TM4C123G platform for ARM® Cortex™-M4-based microcontrollers

The EK-TM4C123GXL also features programmable user buttons and an RGB LED for custom applications. The stackable headers of the Tiva C Series TM4C123G LaunchPad BoosterPack XL Interface make it easy and simple to expand the functionality of the Tiva C Series LaunchPad when interfacing to other peripherals with compatible BoosterPacks.

The Tiva C Series LaunchPad provides an easy and inexpensive way to develop applications with the

  1. Tiva C Series TM4C123GH6 microcontroller
  2. .

    Original Product Link http://www.ti.com/tool/EK-TM4C123GXL

    The Tiva C Series TM4C123G LaunchPad evaluation board offers these features:

    1. Tiva C Series TM4C123GH6 microcontroller
    2. USB Micro-AB connector: Device mode default configuration, Host/OTG modes supportable
    3. RGB user LED
    4. Two user switches (application/wake)
    5. Available I/O brought out to headers on a 0.1" grid
    6. Onboard In-Circuit Debug Interface (ICDI)
    7. Switch-selectable power sources: ICDI, USB device
    8. Reset switch
    9. Preloaded RGB quickstart application
    10. Supported by TivaWare™ for C Series software, including the USB Library and the Peripheral Driver Library
    11. Tiva C Series TM4C123G LaunchPad BoosterPack XL interface—features stackable headers to expand the capabilities of the 40-pin Tiva C Series LaunchPad evaluation platform

    The EK-TM4C123GXL works with TivaWare for C Series, as well as several different software toolchains, including:

    1. Keil
    2. Sourcery CodeBench
    3. IAR Tools
    4. CodeComposer Studio

    Click here to download the Tiva C Series LaunchPad software.

    Get ICDI drivers here.

    The Tiva C Series TM4C123G LaunchPad Evaluation Kit includes the following items:

    1. Tiva C Series LaunchPad Evaluation board
    2. USB Micro-B plug to USB-A plug cable
    3. ReadMe First quick-start guide
