| Features | Descriptions |
| LCD Languages | English/Chinese, English/Deutch, English/Turkish, English/Italiano, English/Espanol, English/Francais, English/Russian |
| Inputs | 3x Configurable digital, 3x Analogue senders, Magnetic Pickup, Charge Alternator D+(WL) inputs |
| Outputs | 6x configurable transistor, Generator Contactor Output |
| Current Measurement | 1 phases CT inputs for Load Current, 1x CT input for Earth Current |
| Voltage Measurement | For 1 phases |
| Case | |
| Dimensions | 111mm x 81mm x 61mm |
| Protection Class | NEMA 4X IP65 at front side |
| Operating Range | |
| DC Battery Supply range | 8 to 32Vdc, max.operating current is 360mA |
| Sender Measurement | 0 to 1300 ohm, accuracy: 1%FS, resolution: 1 ohm |
| Cabin.Temp.Measuremet | |
| Operating / Storage Temp. | -20°C with +70°C / -40°C with +80°C |
| Expansions | |
| Internal | Parameter configuration via RS-232 serial communication |
| GPRS | |
| Embedded WEB server | |
| Serial ModBus | |
| Approvals | CE, GOST-R |
