| Specifications |
UT302C+ |
| Temperature range |
-32℃~1100℃ |
| -25.6℉~2012℉ |
| Accuracy |
≥0℃: ±1.5℃ or ±1.5%; <0℃: ±(1.5℃+0.1℃/℃) |
| ≥32℉: ±3.0℉ or ±1.5%; <32℉: ±(3.0℉+0.1℉/℉) |
| Repeatability |
0.7℃ or 0.7% (1.5℉ or 0.7%) |
| D:S ratio |
20:1 |
| Response time |
250ms |
| Emissivity |
0.1~1.0 (adjustable, stores 5 sets of preset values) |
| Spectral response |
8um~14um |
| Laser power |
< 1mW |
| Features |
| Auto power off |
√ |
| Low battery indication |
√ |
| LCD display |
Color EBTN |
| High/low LED alarm |
√ |
| High/low audible alarm |
√ |
| Data hold/Lock measurement |
√ |
| ℃/℉ selection |
√ |
| MAX/MIN/AVG/DIFF mode |
√ |
| Data storage with date and time |
99 |
| Scheduled measurement |
√ |
| Backlight |
√ |
| Operating temperature |
0℃~50℃ (32℉~122℉) |
| Storage temperature |
-20℃~60℃ (-4℉~140℉) |
| Operating humidity |
<90%RH (non-condensing) |
| Drop test |
1m |
| Tripod mounting hole |
√ |
| General Characterisitics |
| Power |
9V battery |
| Display |
35mm x 35mm |
| Product color |
Red and grey |
| Product net weight |
310g |
| Product size |
172mm x 113.5mm x 53mm |
| Standard accessories |
Battery, carrying bag |
| Standard individual packing |
Gift box, blister, English manual |
| Standard quantity per carton |
10pcs |
| Standard carton measurement |
425mm x 335mm x 365mm |
| Standard carton gross weight |
6.65kg |
